Rolling Steel Fire Door - Model 700
Call Us Now And Receive A Quick Inspection For Your Garage Door
The Model 700 Rolling Steel Fire Door is engineered for maximum fire protection and everyday reliability in commercial and industrial settings. Designed to automatically close in the event of a fire, this heavy-duty fire-rated door offers robust security, energy efficiency, and compliance with the most stringent building codes.
Manufactured with high-quality steel slats and available in various gauges, the Model 700 is UL, FM, and CSFM labeled for up to 4-hour fire protection. It’s ideal for compartmentalizing building areas in warehouses, manufacturing facilities, schools, hospitals, and retail environments.
Key Features:
- Fire-Rated Performance: UL-listed and labeled for up to 4 hours of fire protection.
- Automatic Closing System: Activates upon fire alarm or heat detector signal to help contain fire and smoke.
- Durable Construction: Built from heavy-duty galvanized or stainless steel slats for long-lasting strength.
- Custom Sizes: Available in a wide range of dimensions to fit virtually any opening.
- Finish Options: Standard galvanized finish, powder coating, and custom colors available.
- Safety and Code Compliance: Meets NFPA 80 and local fire code requirements.
Optional Enhancements:
- Smoke seals and gasketing for added smoke and draft control.
- Vision panels for visibility while maintaining protection.
- Fire-rated pass doors for egress within larger openings.
Whether you need to protect a fire-rated wall opening or ensure code compliance in a high-traffic facility, the Model 700 Rolling Steel Fire Door delivers peace of mind with dependable fire and life safety performance.
Key Product Features
- Fire-Rated Protection
This door is UL, FM, and CSFM-labeled, providing up to 4 hours of fire protection to help keep fire and smoke at bay. - Automatic Closing System
It comes with a reliable automatic closing system that activates through fire alarms, smoke detectors, or fusible links, ensuring safety when it matters most. - Heavy-Duty Steel Construction
Crafted with robust interlocking slats, you can choose from galvanized, stainless steel, or aluminum, all designed to withstand high-cycle usage. - Custom Sizes & Mounting Options
We can manufacture this door to fit almost any opening, with options for face-of-wall or between-jamb mounting. - Finish & Color Options
Choose from a standard galvanized finish or opt for a powder coating available in over 180 RAL colors to perfectly complement your building’s aesthetic. - Quiet & Smooth Operation
Engineered for a precision-balanced design, this door rolls quietly, making it ideal for environments where noise is a concern. - Optional Features
– Smoke seals and gaskets
– Vision panels
– Fire-rated pass doors
– Motorized or manual operation - Code Compliant
Rest assured, this door meets NFPA 80, IBC, ADA, and local building/fire codes, making it perfect for both commercial and industrial facilities.
Slat Profiles
- Flat Slat (Type FS)
This type boasts a clean, modern look. It’s perfect for situations where a sleek design is key. Plus, it offers top-notch coverage and fire protection while keeping visual lines to a minimum. - Curved Slat (Type C)
With its traditional curved shape, this option adds extra strength and rigidity. You’ll often find it in industrial environments or larger door openings, as it improves wind resistance and enhances rolling action. - Perforated or Fenestrated Slats (Optional)
These are available on select profiles, allowing light to pass through or providing ventilation while still maintaining fire-rated performance (just a heads up: the rating might change based on the configuration). They’re commonly used in parking garages, retail spaces, or warehouse doors that need airflow or visibility. - Vision Slats (with Fire-Rated Glazing) (Optional Upgrade)
These slats come with narrow rectangular vision windows made from UL-rated fire glass. They let you see through the door without sacrificing fire protection.
Material Options:
- Galvanized Steel – This is the standard choice, known for being corrosion-resistant and budget-friendly.
- Stainless Steel – Ideal for environments with high moisture or where cleanliness is a priority.
- Aluminum – Lightweight and rust-resistant, though it comes with limited fire ratings.
Operation Options
- Manual Operation
Use a chain hoist or crank for openings that don’t require a motor. - Motorized Operation
An electric operator that integrates fire-release features and automatically closes during alarm situations. - Auto-Resettable Operator (Optional)
This option lets the door reset itself after a fire test or drop, which helps cut down on downtime and service calls.
Fire Safety Accessories
- Automatic Closing Devices
These include fusible links, devices that release when an alarm is triggered, and electromagnetic releases that work with building alarm systems. - Smoke Seals & Gasketing
These features improve the containment of smoke and drafts, ensuring compliance with smoke control regulations. - Vision Panels with Fire-Rated Glass
Incorporate UL-rated glazing for visibility while still providing fire protection. - Fire-Rated Pass Door (Wicket Door)
This is a personnel door built into the fire curtain, allowing safe exit without needing to lift the entire door.
Color Options
White
Gray
Beige
Brown
RAL Powder Coat
Brochure
Fire Door 700 FireStar
Brochure
Rolling Door Systems
Brochure
Rolling Door End User Manual
Brochure
Model 700 Wind Load Options
Brochure
Firestar Door Operator System Warranty
Brochure
Fire-Rated Rolling Steel Doors Warranty – Models 700
Warranty Terms:
Covers labor and replacement parts installed by our team.
Does not cover damage caused by accidents, misuse, or external factors.
Warranty service must be requested within the coverage period.
For warranty claims or service inquiries, contact us here. Your satisfaction is our priority!
